Coda 06x Phono Preamplifier

Circuit Specifications

Frequency Response: +/- .2dB of RIAA with subsonic roll off @ 14Hz

Distortion: < .01% from 20Hz to 20kHz @ 3V peak into 600 or higher shunted by 100pf or less

Gain: unbalanced output - 37dB @ 1kHz balanced output - 46dB @ 1kHz

Maximum Output: 12V peak

Noise: >87dB referenced to 1V output

Input Capacitance: 100pF to 1000pF

Input Impedance: 22Ω to 47kΩ

Output Impedance: 75Ω non-reactive unbalanced 150Ω non-reactive balanced

Crosstalk: 70dB @ 20kHz

Power Supply

Independently regulated with shielded toroidal transformer and 25,000uF of capacitance

Dimensions

Height: 2.5” Faceplate, 2.85” Overall

Width: 18.0” Faceplate, 17.0” Chassis Depth: 9.75” Overall

Weight: 14 lbs. Shipping
